The BIM-04-1 is a multi-Temperature module that allows you to add up to 3 additional temperature readings to your VFD3 (rev G) or VHX gauges. The BIM-04-1 utilizes Ground Isolated senders for easy installation without the headache of engine grounding.
Pressure Inputs:
- Temperature (generic fluid or air)
- Water Temp
- Oil Temp
- Transmission Temp
- Differential Temp
Input senders and specifications:
| Gauge Display |
Sender Part # |
Range |
High Warning |
| TEMP |
SEN-04-5 |
100- 320F |
131- 320F |
| WATER |
SEN-04-5 |
100- 320F |
NONE SAME AS SYSTEM |
| OIL |
SEN-04-5 |
100- 320F |
131- 320F |
| TRANS |
SEN-04-5 |
100- 320F |
131- 320F |
| DIFF |
SEN-04-5 |
100- 320F |
131- 320F |
* All temperature readings will display either Fahrenheit or Celsius depending on the setting selected by the gauge cluster.
For Ford Flathead motors there is a special option that allows the system to display the highest temperature reading in the main display at all times. The lowest temperature reading will display in the information center.
**The BIM-04-1 is designed to supply information to the VFD3 rev. G and VHX control box instrument systems only. Earlier control boxes (with an aluminum case) are not compatible with the BIM family of Expansion Modules.
